Underwater Camera

[camera]

Camera

Underwater camera capture of seabed
Resolution
4K, 1.1” Global Shutter
Dimensions
160x220 mm
HFOV (in water)
83.9 deg
Depth Rating
1000 m
Weight
1.2 kg

▌Description

A compact, high-resolution underwater camera engineered for AUVs and ROVs, optimized for dependable 4K capture, stable timing, and straightforward system integration. Built for real-world subsea operations, it delivers crisp imagery you can use directly for inspection, mapping, and analysis. The camera is designed to be used in conjunction with the Skarv software ecosystem to process and manage the data. Skarv software provides tools for 2D and 3D imaging, object detection-segmentation and classification, image enhancement, and surveillance functions such as change detection and object tracking.

Aquaculture inspection
Underwater Camera capture of seabed
Aquaculture inspection

▌Specifications

Resolution

4K, 1.1” Global Shutter

Dimensions

160x220 mm

Weight

1.2 kg

Depth Rating

1000 m

HFOV (in water)

83.9 deg

Power

30-50 VDC

Interfaces

Gigabit ethernet

Connector

Cobalt 14 19-pin

Onboard compute

Yes

Strobe trigger IO

Yes

Self contained

Yes

All spesifications subject to change without notice.
